100 Height T - Wire Tray Straight Section

Connection
Support System
Installations

Strengthening Bar Kit

Fast Docking Bar

L Connector Kit

Axis Coupler Kit

Screwless Coupler

R140 Link Span Kit

R300 Link Span Kit

T-Wire Cable Tray Benefits

Can be stacked for multilevel installations to save space during transportation or in storage.

Height（mm）	Width（mm）	Sectional View
100	100
100	150
100	200
100	300

Item Name	Wire Dia	Height		Width		Length		Weight (Per Meter)		Electroplate	Hot Dip Galvanizing	Powder Coating	Stainless Steel 304	Stainless Steel 316L
Item Name	mm	mm	inch	mm	inch	mm	inch	lb	kg	Electroplate	Hot Dip Galvanizing	Powder Coating	Stainless Steel 304	Stainless Steel 316L
T-Wire Tray Straight Section	4	100	4	100	4	3000	118	6.80	3.09	BS24321	BS24322	BS24323	BS24324	BS24325
T-Wire Tray Straight Section	4	100	4	150	6	3000	118	7.81	3.55	BS24331	BS24332	BS24333	BS24334	BS24335
T-Wire Tray Straight Section	4	100	4	200	8	3000	118	8.79	3.99	BS24341	BS24342	BS24343	BS24344	BS24345
T-Wire Tray Straight Section	4	100	4	300	12	3000	118	10.83	4.92	BS24351	BS24352	BS24353	BS24354	BS24355

Item Name	Wire Dia	Height		Width		Length		Weight (Per Meter)		Electroplate	Hot Dip Galvanizing	Powder Coating	Stainless Steel 304	Stainless Steel 316L
Item Name	mm	mm	inch	mm	inch	mm	inch	lb	kg	Electroplate	Hot Dip Galvanizing	Powder Coating	Stainless Steel 304	Stainless Steel 316L
T-Wire Tray Straight Section	5	100	4	100	4	3000	118	10.63	4.83	BS25321	BS25322	BS25323	BS25324	BS25325
T-Wire Tray Straight Section	5	100	4	150	6	3000	118	12.21	5.55	BS25331	BS25332	BS25333	BS25334	BS25335
T-Wire Tray Straight Section	5	100	4	200	8	3000	118	13.73	6.24	BS25341	BS25342	BS25343	BS25344	BS25345
T-Wire Tray Straight Section	5	100	4	300	12	3000	118	16.90	7.68	BS25351	BS25352	BS25353	BS25354	BS25355

Item Name	Wire Dia	Height		Width		Length		Weight (Per Meter)		Electroplate	Hot Dip Galvanizing	Powder Coating	Stainless Steel 304	Stainless Steel 316L
Item Name	mm	mm	inch	mm	inch	mm	inch	lb	kg	Electroplate	Hot Dip Galvanizing	Powder Coating	Stainless Steel 304	Stainless Steel 316L
T-Wire Tray Straight Section	6	100	4	100	4	3000	118	15.31	6.96	BS26321	BS26322	BS26323	BS26324	BS26325
T-Wire Tray Straight Section	6	100	4	150	6	3000	118	17.58	7.99	BS26331	BS26332	BS26333	BS26334	BS26335
T-Wire Tray Straight Section	6	100	4	200	8	3000	118	19.78	8.99	BS26341	BS26342	BS26343	BS26344	BS26345
T-Wire Tray Straight Section	5	100	4	300	12	3000	118	24.33	11.06	BS26351	BS26352	BS26353	BS26354	BS26355
