30 Height U - Wire Tray Straight Section

Connection
Support System
Installations

Strengthening Bar Kit

Fast Docking Bar

L Connector Kit

Axis Coupler Kit

Screwless Coupler

R140 Link Span Kit

R300 Link Span Kit

Height（mm）	Width（mm）	Sectional View
30	50
30	100
30	150
30	200

Item Name	Wire Dia	Height		Width		Length		Weight (Per Meter)		Electroplate	Hot Dip Galvanizing	Powder Coating	Stainless Steel 304	Stainless Steel 316L
Item Name	mm	mm	inch	mm	inch	mm	inch	lb	kg	Electroplate	Hot Dip Galvanizing	Powder Coating	Stainless Steel 304	Stainless Steel 316L
U-Wire Tray Straight Section	4	30	1.2	50	2	3000	118	2.73	1.24	BS14111	BS14112	BS14113	BS14114	BS14115
U-Wire Tray Straight Section	4	30	1.2	100	4	3000	118	3.70	1.68	BS14121	BS14122	BS14123	BS14124	BS14125
U-Wire Tray Straight Section	4	30	1.2	150	6	3000	118	4.70	2.13	BS14131	BS14132	BS14133	BS14134	BS14135
U-Wire Tray Straight Section	4	30	1.2	200	8	3000	118	5.68	2.58	BS14141	BS14142	BS14143	BS14144	BS14145

Item Name	Wire Dia	Height		Width		Length		Weight (Per Meter)		Electroplate	Hot Dip Galvanizing	Powder Coating	Stainless Steel 304	Stainless Steel 316L
Item Name	mm	mm	inch	mm	inch	mm	inch	lb	kg	Electroplate	Hot Dip Galvanizing	Powder Coating	Stainless Steel 304	Stainless Steel 316L
U-Wire Tray Straight Section	5	30	1.2	50	2	3000	118	4.25	1.93	BS15111	BS15112	BS15113	BS15114	BS15115
U-Wire Tray Straight Section	5	30	1.2	100	4	3000	118	5.79	2.63	BS15121	BS15122	BS15123	BS15124	BS15125
U-Wire Tray Straight Section	5	30	1.2	150	6	3000	118	7.33	3.33	BS15131	BS15132	BS15133	BS15134	BS15135
U-Wire Tray Straight Section	5	30	1.2	200	8	3000	118	8.87	4.03	BS15141	BS15142	BS15143	BS15144	BS15145

Item Name	Wire Dia	Height		Width		Length		Weight (Per Meter)		Electroplate	Hot Dip Galvanizing	Powder Coating	Stainless Steel 304	Stainless Steel 316L
Item Name	mm	mm	inch	mm	inch	mm	inch	lb	kg	Electroplate	Hot Dip Galvanizing	Powder Coating	Stainless Steel 304	Stainless Steel 316L
U-Wire Tray Straight Section	6	30	1.2	50	2	3000	118	6.12	2.78	BS16111	BS16112	BS16113	BS16114	BS16115
U-Wire Tray Straight Section	6	30	1.2	100	4	3000	118	8.34	3.79	BS16121	BS16122	BS16123	BS16124	BS16125
U-Wire Tray Straight Section	6	30	1.2	150	6	3000	118	10.56	4.80	BS16131	BS16132	BS16133	BS16134	BS16135
U-Wire Tray Straight Section	6	30	1.2	200	8	3000	118	12.76	5.80	BS16141	BS16142	BS16143	BS16144	BS16145
